Continuous Band Sealer Series SPM-200

The continuous sealing machine uses Korean technology and the key components are from Korea. The equipment is stable, the seal is beautiful and firm, and it is suitable for continuous sealing operations of food, medical, chemical and so on. Elimination of bag offset, wrinkles in the seal and other issues.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button
  • SPM-200

  • CHIKO

  • ZK

ModelSPM-200
Power220V,50/60,920W
Sealing width10mm
table load bearingMax 15kg
Conveyor belt specificationW220*L1450mm
Temperature regulation range0~300℃
SpeedMax 21meter/minute
Weight111kg
SizeW700*L1450*H1500mm


The continuous sealing machine uses Korean technology and the key components are from Korea. The equipment is stable, the seal is beautiful and firm, and it is suitable for continuous sealing operations of food, medical, chemical and so on. Elimination of bag offset, wrinkles in the seal and other issues.

1.Durable due to the sturdy and thick material.

2. Use the best bearings and chains to make the life long and prevent elongation.

3. Due to the installation of the emergency switch, the user can prevent danger when it is mistaken or mishandled.

4. Due to the continuous heating method, the width of the paper bag can be used without limit.

5. The pressure adjustment of the hot plate can be adjusted slightly according to the thickness of the paper bag.

6. Due to the use of a high-performance thermostat, the temperature can be properly adjusted and the most suitable paste temperature can be maintained.

7. Depending on the characteristics of the product used and the size of the paper bag, the height of the conveyor, the angle of inclination and the width of the conveyor can be adjusted.

8. Since the press bearing is installed, even if dust adheres to the product, it can be safely pasted.

9. The main drive part is covered with a film, and the stainless steel material is used for durability and is not easily corroded.

10. Sealing Band and heater replacement is easy.

11, can adjust the operating speed, the general production line can be operated.
